CAPILLARI_1 - Keraglass

Capillary tubes for biochemical wards

Capillary tubes for determination of acid-base equilibrium

Dimensional tolerance:

125/100, 125/140, 125/200, 100/80, 100/110, 90/100

Lenght:

± 0,8 mm

Volume:

± 0,8 μl

Qualitative parameters:

Capillary tubes are delivered with antiprecipitation treatment (natrium, lithium, ammonium heparin according to the customer demand) or without antiprecipitation treatment. Together with the capillary on the antiprecipitation treatment, the wires for capillaries are normally provided for mixing, which can also be ordered separately or unordered / needed to be specified at the moment of the order. Capillary tubes are produced from glassmelt SIMAX.

Using:

For determination of acid-base equilibrium and blood gases with instruments CORNING (168-200), AVL (938-995), RADIOMETER (ABL 2-500, BMS 2 a 3), IL (213-1 400).

Download PDF: Capillary tubes for determination of acid-base equilibrium

Product
name

125/100

Lenght

[mm]

125

Internal
Diameter

[mm]

1,0

Volume

[µl]

100

Minimum Wall Thickness

[mm]

0,18

Pieces
per pack

100

Product
name

125/140

Lenght

[mm]

125

Internal
Diameter

[mm]

1,2

Volume

[µl]

140

Minimum Wall Thickness

[mm]

0,18

Pieces
per pack

75

Product
name

125/200

Lenght

[mm]

125

Internal
Diameter

[mm]

1,43

Volume

[µl]

200

Minimum Wall
Thickness

[mm]

0,18

Pieces
per pack

50

Product
name

100/80

Lenght

[mm]

100

Internal
Diameter

[mm]

1,0

Volume

[µl]

80

Minimum Wall
Thickness

[mm]

0,18

Pieces
per pack

100

Product
name

100/110

Lenght

[mm]

100

Internal
Diameter

[mm]

1,2

Volume

[µl]

110

Minimum Wall
Thickness

[mm]

0,18

Pieces
per pack

75

Product
name

90/100

Lenght

[mm]

90

Internal
Diameter

[mm]

1,2

Volume

[µl]

100

Minimum Wall
Thickness

[mm]

0,18

Pieces
per pack

75
